| Art No. | WLL | Sheave Dia | A | B | C | D | Wire Rope | Weight | Type |
| Ton | mm | mm | mm | mm | mm | mm | kg/pc | ||
| BL04-075SH | 0.50 | 75.00 | 178.00 | 85.00 | 26.00 | 12.00 | 8.00 | 1.10 | Shackle |
| BL04-100SH | 1.00 | 100.00 | 235.00 | 121.00 | 34.00 | 16.00 | 8.00 | 1.80 | Shackle |
| BL04-125SH | 1.50 | 125.00 | 305.00 | 145.00 | 38.00 | 18.00 | 9.00 | 3.50 | Shackle |
| BL04-150SH | 2.00 | 150.00 | 350.00 | 180.00 | 41.00 | 22.00 | 12.00 | 5.10 | Shackle |
| BL04-200SH | 4.00 | 200.00 | 425.00 | 225.00 | 46.00 | 28.00 | 16.00 | 11.50 | Shackle |
| BL04-250SH | 5.00 | 250.00 | 495.00 | 275.00 | 60.00 | 28.00 | 22.00 | 17.00 | Shackle |
| BL04-075E | 0.50 | 75.00 | 178.00 | 85.00 | 50.00 | 12.00 | 8.00 | 1.80 | Oval Eye |
| BL04-100E | 1.00 | 100.00 | 235.00 | 121.00 | 61.00 | 16.00 | 8.00 | 2.80 | Oval Eye |
| BL04-125E | 1.50 | 125.00 | 305.00 | 145.00 | 73.00 | 18.00 | 9.00 | 5.50 | Oval Eye |
| BL04-150E | 2.00 | 150.00 | 350.00 | 180.00 | 83.00 | 22.00 | 12.00 | 8.50 | Oval Eye |
| BL04-200E | 4.00 | 200.00 | 425.00 | 225.00 | 93.00 | 28.00 | 16.00 | 16.50 | Oval Eye |
| BL04-250E | 5.00 | 250.00 | 495.00 | 275.00 | 115.00 | 28.00 | 22.00 | 25.50 | Oval Eye |
